PERSONNEL TRACKING BADGE

Purelink’s nanoEdge^TM Personnel Tracking Badge is an active RFID tag built for RTLS applications. It is a location badge that goes beyond access control to deliver constant building-wide location of employees, visitors and contractors, with an accuracy of ± 2 meters. The nanoEdge^TM Personnel Tracking Badge (PLK-NT030-20) is an access control identification badge with GPS-like functions. The PLK-NT030-20 wireless badge is recommended for use with Purelink’s Bluefairy suite of software to deliver enterprise-wide location-aware applications for business process management, safety procedures, control and security.

Technical Specifications

• 4.5mm thickness
• 85mm X 54mm X 4.5mm (about the size of a credit card)
• 200-meter range
• Location accuracy: ± 2 m
• 5-year battery lifetime at a blink rate of 1/sec
• IP54 rated

Options

• Integrated access control chip
• Integrated motion detector
• Transmission rate:
  • 1 per second (lifetime 5 years)
  • 5 per second (lifetime 2.5 years)

Application

• Tracking of employees, visitors & contractors
• Security & safety
• Worker attendance
• Enterprise process analysis & control

Avalaible in 5 colors
PLK-NT030-20
Starting From*: $ 25.95

Purchase

Download Spec Sheet

Green Program

Videos >

Software >

Badges & Tags >

Products >

*Sold in packs of 25. All prices are in USD.
Prices are subject to change without notice.
